Self-contained trigger/assembly installs in minutes and delivers a light, smooth, match-grade trigger pull free of grittiness, with an ultra-crisp letoff and short reset. Simply remove factory trigger and safety selector, drop in the module, reinstall selector and pins, and you’re ready to shoot. Completely new engagement geometry produces a light 3-lb. pull and crisp release without compromising reliability or safety. The two-stage design is adjustable for sear engagement, with a first-stage takeup of approximately 6 ounces, followed by actual sear movement taking up the rest of the weight—the reverse of the military two-stage AR trigger pull profile. Instead, the shooter can build force steadily, maintaining precise control and keeping his attention on the target. After release, reset travel is only .030", less than half the .070" typical of standard match triggers, to aid in fast, accurate follow-up shots. The sear captures the hammer at the back instead of near the pivot point to help produce the light pull and maintain safety. A second, independent, intercepting sear is positioned to block the hammer if it slips off the primary sear, as when the weapon is dropped or suffers hard impact. If the intercepting sear captures the hammer, pulling the trigger will still fire the rifle, though with a heavier pull weight. In addition, the Gold system uses the rifle’s factory safety to positively capture the hammer, like an M1 Garand, and roll it back below the primary sear for an extra margin of safety. A lightweight aluminum housing contains the entire system and maintains the correct tolerances between the working parts. The receiver pins serve only to anchor the module in the receiver, with no effect on trigger function.
SPECS: Trigger/Hammer – Wire EDM cut S7 tool steel. Housing – Aluminum, anodized, black. AR Gold fits any mil-spec AR-15 with .154" trigger and hammer pin holes. Will not fit rifles with Colt-type sear block or AR-style .308 rifles.
Un disparador de precisión para tu AR-15.
El AR-15 AR GOLD TRIGGER CURVED de AMERICAN TRIGGER CORPORATION es un sistema de control de fuego que se instala fácilmente y ofrece un disparo ligero, seguro y de calidad de competición.
Descripción del producto
Este disparador/autoinstalable se coloca en minutos y proporciona un disparo ligero y suave, libre de asperezas, con un letoff ultra nítido y un reset corto. Simplemente quita el disparador de fábrica y el selector de seguridad, coloca el módulo, reinstala el selector y los pasadores, y ¡estás listo para disparar!
La nueva geometría de enganche produce un peso de disparo ligero de 3 libras y una liberación nítida sin comprometer la fiabilidad o la seguridad. El diseño de dos etapas es ajustable para el enganche del sear, con un primer tramo de aproximadamente 6 onzas, seguido por el movimiento real del sear que toma el resto del peso, a diferencia del perfil de disparo de dos etapas del disparador militar AR.
De este modo, el tirador puede aumentar la fuerza de manera constante, manteniendo un control preciso y enfocando su atención en el objetivo. Después de la liberación, el recorrido de reset es solo .030", menos de la mitad de los .070" típicos de los disparadores de competición estándar, lo que ayuda en disparos de seguimiento rápidos y precisos.
El sear captura el martillo en la parte posterior en lugar de cerca del punto de pivote, lo que ayuda a producir un disparo ligero y mantener la seguridad. Un segundo sear independiente, que intercepta, está posicionado para bloquear el martillo si se desliza del sear principal, como cuando el arma se cae o sufre un impacto fuerte. Si el sear interceptador captura el martillo, tirar del disparador todavía disparará el rifle, aunque con un peso de disparo más pesado.
Además, el sistema Gold utiliza la seguridad de fábrica del rifle para capturar positivamente el martillo, como en un M1 Garand, y lo devuelve por debajo del sear principal para un margen extra de seguridad. Una carcasa de aluminio ligera contiene todo el sistema y mantiene las tolerancias correctas entre las piezas móviles. Los pasadores del receptor sirven solo para anclar el módulo en el receptor, sin afectar la función del disparador.
Especificaciones
- Disparador/Martillo: Acero S7 cortado por Wire EDM.
- Carcasa: Aluminio, anodizado, negro.
- Compatibilidad: AR Gold se adapta a cualquier AR-15 mil-spec con orificios de pasador de disparador y martillo de .154". No se adapta a rifles con bloque de sear tipo Colt o rifles AR estilo .308.
