With the exception of the .240 Weatherby Magnum, most belted, magnum cartridges are based on the .375 H&H Magnum case. Therefore, they all use the same headspace gauges. The following is a partial listing of those cartridges which use the same Belted Magnum Headspace Gauges: .257 Weatherby Mag., 6.5 Rem. Mag., .264 Win. Mag., .270 Weatherby Mag., 7mm Rem. Mag., 7mm Weatherby Mag., 7mm STW, .300 H&H Mag., .300 Weatherby Mag., .300 Win. Mag., .30-.338 Win. Mag., .308 Norma Mag., 8mm Rem., .338 Win. Mag., .340 Weatherby Mag., .350 Rem. Mag., .358 Norma Mag., .375 H&H Mag., .416 Rem. Mag., .458 Win. Mag.MIXING AND MATCHING BRANDS OF HEADSPACE GAUGES - Don't do it!! That's the short answer, here's why. It boils down to tolerance stacking. Each Headspace Gauge manufacturer works within a range specified by SAAMI. Manufacturer "A" may work at the high end of the range while Manufacturer "B's" gauges are in the middle of the tolerance range. Mixing the two could give an inaccurate reading. By sticking with one brand within a particular caliber, you will eliminate a variable. If you have a Forster, .308 GO gauge, get a Forster, .308 NO GO. Use Clymer with Clymer and Manson Precision with Manson Precision, etc. You can use any brand of headspace gauge with any other brand of chambering reamer. e.g. Forster Headspace Gauges with Clymer Reamers, Manson Precision Gauges with JGS Reamers, etc.
Determina el espacio de cabezal correcto para tus cartuchos belted magnum.
Con la excepción del .240 Weatherby Magnum, la mayoría de los cartuchos belted magnum se basan en el cartucho .375 H&H Magnum. Por lo tanto, todos ellos utilizan los mismos medidores de espacio de cabezal. A continuación, se presenta una lista parcial de esos cartuchos que utilizan los mismos medidores de espacio de cabezal belted magnum:
- .257 Weatherby Mag.
- 6.5 Rem. Mag.
- .264 Win. Mag.
- .270 Weatherby Mag.
- 7mm Rem. Mag.
- 7mm Weatherby Mag.
- 7mm STW
- .300 H&H Mag.
- .300 Weatherby Mag.
- .300 Win. Mag.
- .30-.338 Win. Mag.
- .308 Norma Mag.
- 8mm Rem.
- .338 Win. Mag.
- .340 Weatherby Mag.
- .350 Rem. Mag.
- .358 Norma Mag.
- .375 H&H Mag.
- .416 Rem. Mag.
- .458 Win. Mag.
MEZCLANDO Y COMBINANDO MARCAS DE MEDIDORES DE ESPACIO DE CABEZAL - ¡No lo hagas! Esa es la respuesta corta, aquí está el porqué. Se reduce a la acumulación de tolerancias. Cada fabricante de medidores de espacio de cabezal trabaja dentro de un rango especificado por SAAMI. El fabricante "A" puede trabajar en el extremo superior del rango, mientras que los medidores del fabricante "B" están en el medio del rango de tolerancia. Mezclar los dos podría dar una lectura inexacta. Al ceñirte a una sola marca dentro de un calibre particular, eliminarás una variable. Si tienes un medidor .308 GO de Forster, consigue un .308 NO GO de Forster. Usa Clymer con Clymer y Manson Precision con Manson Precision, etc. Puedes usar cualquier marca de medidor de espacio de cabezal con cualquier otra marca de reamer de cámara, por ejemplo, los medidores de espacio de cabezal Forster con los reamers Clymer, los medidores Manson Precision con los reamers JGS, etc.
